Capacity

Capacity

We handle large scale high volume runs, as well as one-off prototypes.

Both Low and High Capacity Engineering

Machining Centres

Leadwell Vertical Machining Centre Number 1

  • Mitsubishi controls with FAPT programming
  • BT40 spindle nose
  • 24 Pre-select tool capacity
  • X = 760mm
  • Y = 400mm
  • Z = 700mm
  • ully integrated 4th axis

Leadwell Vertical Machining Centre Number 2

  • Mitsubishi controls
  • BT40 spindle nose
  • 24 Pre-select tool capacity
  • X = 760mm
  • Y = 400mm
  • Z = 600mm

Leadwell Vertical Machining Centre CNC

  • Mitsubishi controls
  • BT40 spindle nose
  • 24 Pre-select capacity
  • X = 1800mm
  • Y = 750mm
  • Z = 700mm

Fadal Vertical CNC Machining Centre

  • BT40 spindle nose
  • 24 Pre-select capacity
  • X = 810mm
  • Y = 410mm
  • Z = 700mm

CAD-CAM

Cad-Cam milling and turning software. Complete CAD interface with DXF & IGE’s importation. 3 pocketing. Part and Tool simulation. Full off-line programming with DNC linkage.

Turning Centres

Colchester Tornado CNC Turning Lathe Number 1:

  • Slant Bed Lathe
  • Fanuc OT controls
  • Max Swing X = 300mm
  • Max Z = 350mm
  • Hydra Feed Magazine Bar Feed

Colchester Tornado CNC Turning Lathe Number 2:

  • Slant Bed Lathe
  • Fanuc OT controls
  • Fully Automatic Hydra Feed Magazine Bar Feed
  • (1.2mtr) with 52mm dia through spindle
  • Max Swing X = 300mm
  • Max Z = 350mm
Victor V Turn CNC Turning Lathe:
Allows high speeds to be obtained while maintaining good rigidity.

  • Slant Bed Lathe
  • Fanuc OT controls
  • Max Swing X = 400mm
  • Max Z = 350mm
Kia Turn 21 Yaznak CNC Turning Lathe:
High speed lathe designed to provide superior rigidity, accuracy and surface finishes.

  • Slant Bed Lathe
  • Crawford collet chuck
  • Fully Automatic Hydra Feed Magazine Bar Feed
  • (1.2mtr) with 52mm dia through spindle
  • Parts catcher and tails
  • Max X = 200mm
  • Max Z = 250mm

Kia Turn CNC Turning Lathe:

  • Slant Bed Lathe
  • Fanuc OT controls
  • Max Swing X = 300mm
  • Max Z = 350mm

CMZ CNC Turning Lathe:

  • Full C Axis
  • Slant Bed Lathe
  • Fanuc OT controls
  • Max Swing X = 550mm
  • Max Z = 1200mm

Miyano ABX-51SYY/64SYY CNC Turning Center:

  • Full C Axis
  • Dual Turrets
  • Fanuc 31i OT controls
  • Max Machining dia = 51mm/64mm
  • Up to 24 tools per turret

Cincom L20E-IX CNC Sliding Head Lathe:

  • Full C Axis
  • Sliding Head Lathe
  • Mitsubishi M70 series hardware
  • Max Machining dia = 20mm
  • 7 rotary spindles

Ancillary Equipment: Auto band saw, 1.5 Tonne Fork Lift Truck, Linishing, Engraving & De-burring Equipment. Conventional Lathes/milling machines.

B & A Precision Engineering have the capacity to manufacture almost any component & handle large scale high volume runs, as well as one-off prototypes. Contact us on 01772 330321
